BMW 3 Series Estate 330e 22.3 kWh M Sport 5dr Step Auto

Brakes

ABS:

Ventilated front and rear disc brakes:

Automatic Stability Control (ASC):

Cornering brake control:

DSC - Dynamic Stability Control:

Dynamic brake control:

Dynamic Traction Control - DTC:

Dry braking:

Electric parking brake including automatic hold function and automatic release of the parking brake when driving off:

Drive-off assistant:

Seats

Heated front seats:

Front and rear headrests:

3 seat bench in 2nd row:

40:20:40 split folding rear seat with loading system:

Single front passenger seat:

Body Glass

Rear wiper:

Windscreen washer jets:

Rain sensor with automatic headlight activation:

Electric windows - front and rear, with open/close fingertip control, anti-trap facility and comfort closing:

Heat protection glazing on front windows and windscreen:

Interior Features

Through load system:

Anthracite headlining:

Toolkit located in luggage compartment:

Folding rear centre armrest with 2 cupholders:

12V power socket in front storage compartment:

Armrest integrated in front and rear door trim + front centre console armrest:

Height adjustable mechanically and infinitely variable steering column:

2 front cupholder in centre console with clamping elements and matt black inlay:

Battery in luggage compartment:

Lashing eyelets in luggage compartment:

BMW ID:

Illuminated glove compartment:

Cruise control operation in steering wheel:

Driving experience mode switch:

3 spoke M Sport multifunction flat bottom leather steering wheel:

Security

Locking wheel bolts:

Centre lock switch:

Alarm system:

Electronic vehicle immobiliser:

Closing system with central locking:

Safety

Side impact protection:

Warning triangle and first aid kit:

Child locks on rear doors:

Front airbag deactivation:

3x3 point rear seatbelts:

BMW emergency call:

Plastic fuel tank:

Crash sensor activating of airbags, Unlocking doors, hazard warning lights, interior light, safety battery terminal:

Tyre pressure sensors:

Driver and front passenger with seat occupancy detection for driver's and passenger side:

Head airbags in 1st and 2nd row, head protection at side, curtain airbags open from headliner above 1st and 2nd row:

Driver and passenger side airbags, body protection at side and airbags deploy from seat backrests:

Front airbags for driver and front passenger:

Exterior Lights

Reversing lights:

LED daytime running lights:

LED rear lights:

Automatic headlight beam throw control with load dependent regulating reaction, dynamic compensation of braking dive and acceleration squat:

Welcome lights in interior and door handle area:

Follow me home headlight function:

LED 3rd brake light:

LED turn indicator:

Bi-LED Low and high beam headlights:

Driving Mirrors

Auto dimming rear view mirror:

Interior Lights

Front reading light:

Illuminated luggage compartment:

Illuminated armrest storage compartment:

Carpets/Rugs

Front and rear velour floor mats:

Wheels - Spare

Tyre repair kit:

Exterior Body Features

High gloss shadow line roof rails:

Front and rear bumper system with replaceable deformation elements:

Door sill strips:

Model designation on right side of tailgate:

High gloss chrome kidney frame with high gloss black kidney struts:

Fading support:

Side frame decorative moulding black matt:

Front apron plastic in body colour:

One piece front bumper cover including towing eye cover in body colour:

Licence plate panel integrated into front bumper and tailgate:

Body colour roof fin:

Fuel filler flap - right rear in body colour:

Rear side wing doors:

BMW emblem, engine compartment lid and tailgate:

Visible exhaust tailpipe finisher:

Matt black window recess cover:

Matt black B-pillar finsher:

M high gloss shadow line exterior trim:

Driver Information

BMW Teleservices:

Oil sensor for level and grade:

Shifting point display:

BMW iDrive:

Live cockpit plus with Navigation + 12.3" instrument display + 14.9" display, Intelligent voice assist, 2 USB, 4G LTE connect:

ConnectedDrive Services - last state call:

Driver Convenience

Attentiveness assist:

Active guard plus:

Vanity Mirrors

Sunvisors with illuminated vanity mirrors and ticket pocket:

Entertainment

DAB tuner:

Packs

Connected pack professional - 3 Series Saloon/Touring:

Parking assistant pack - 3 Series:

M sport exterior styling pack - 3 Series Saloon/Touring:

Interior and exterior mirror pack - 3 Series Touring/Saloon:

Heating/Cooling/Ventilation

3 zone automatic air conditioning:

Engine

Electronic differential lock control (EDLC):

Fuel tank breather system:

Driver Aids

Electric bootlid:

Automatic Start/stop button:

Towing

Trailer stabilisation logic:

Chassis/Suspension

Double joint spring strut front axle:

Communication

Bluetooth Wi-Fi interface:

Intelligent voice assist, 2 USB, 4G LTE connect:

Personal e-SIM:

Vehicle Charging

Public mode 3 professional fast charging cable with 5m length:

Plug and charge:

Transmission

Steptronic Sport automatic transmission with steering wheel mounted gearshift paddles launch control and xtreme drive lever control:

Weight and Capacities

Minimum Kerbweight: 1895

Gross Vehicle Weight: 2420

Fuel Tank Capacity (Litres): 40

Max. Towing Weight - Braked: 1500

Max. Towing Weight - Unbraked: 750

Max. Loading Weight: 525

Luggage Capacity (Seats Up): 410

No. of Seats: 5

Max. Roof Load: 75

Luggage Capacity (Seats Down): 1420

Turning Circle - Kerb to Kerb: 11.4

Vehicle Dimensions

Length: 4713

Width: 1827

Wheelbase: 2851

Width (including mirrors): 2068

Height: 1448

Height (including roof rails): 0

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies:

Performance

0 to 62 mph (secs): 6

Top Speed: 143

Engine Power - BHP: 292

Engine Power - PS: 1

0 to 60 mph (secs):

Engine Power - KW: 215

Engine Power - RPM: 5000

Engine Torque - LBS.FT: 310

Engine Torque - NM: 420

Engine Torque - RPM: 1350

Engine Torque - MKG: 42.8

Engine and Drive Train

Cylinders - Bore (mm): 82

Cylinders - Stroke (mm): 94.6

CC: 1998

Cylinders: 4

Cylinder Layout: IN-LINE

Number of Valves: 16

Camshaft: DOHC

Fuel Delivery: TURBO INJECTION

Catalytic Convertor: 1

Engine Layout: NORTH SOUTH

Compression Ratio: 11.0:1

Transmission: SEMI-AUTO

Gears: 8 SPEED

Engine Code: XB1141M1

General

Coin Series: M Sport

Coin Description: e

Standard manufacturers warranty - Years: 3

Standard manufacturers warranty - Mileage: 999999

Safety Concerns?:

Special Edition:

Special Order:

Based On ID: 0

Insurance Group 1 - 50 Effective January 07: 35E

Timing Belt Interval Mileage: 0

Timing Belt Interval Frequency - Months: 0

Badge Power: 292

Badge Engine CC: 2

Vehicle Homologation Class: M1

Generation Mark: 7

Alternative Fuel Qualifying: 1

Tyres

Tyre Size Front: 225/45 R18

Tyre Size Rear: 255/40 R18

Tyre Size Spare: TYRE REPAIR KIT

Wheel Type: 18" ALLOY

Wheel Style: DOUBLE SPOKE STYLE 848M

Alloys?: 1

Space Saver?:

Emissions - ICE

Standard Emissions: EURO 6

Noise Level dB(A): 68

CO: 0.309

HC: 0.011

NOx: 0.014

HC+NOx:

Particles: 0.0005

Electric Vehicle Data

Battery Charging Scenario 1 - Charge Time (Mins): 690

Battery Charging Scenario 1 - Power Supply - kW: 2.3

Battery Charging Scenario 1 - Percentage Change: 0-100

Battery Charging Scenario 2 - Charge Time (Mins): 195

Battery Charging Scenario 2 - Power Supply - kW: 7.4

Battery Charging Scenario 2 - Percentage Change: 0-100

Battery Charging Scenario 3 - Charge Time (Mins): 135

Battery Charging Scenario 3 - Power Supply - kW: 11

Battery Charging Scenario 3 - Percentage Change: 0-100

Battery Charging Scenario 4 - Charge Time (Mins): 0

Battery Charging Scenario 4 - Power Supply - kW:

Battery Charging Scenario 4 - Percentage Change: N

Coupler/Connector Type: Type 2

Standard manufacturers Battery warranty - Years: 8

Standard manufacturers Battery warranty - Mileage: 100000

Battery Capacity in kWh: 22.3

Battery Leased:

Battery Type: Lithium-ion

WLTP - EC (kWh/100km) - Low: 22.2

WLTP - EC (kWh/100km) - Medium: 20

WLTP - EC (kWh/100km) - High: 20

WLTP - EC (kWh/100km) - Extra High: 24.9

WLTP - EC (kWh/100km) - City: 20.7

WLTP - EC (kWh/100km) - Comb: 21.4

WLTP - AER (km) - City: 99

WLTP - AER (km) - Comb: 93

WLTP - Equivalent AER (km) - Low: 93

WLTP - Equivalent AER (km) - Medium: 105

WLTP - Equivalent AER (km) - High: 103

WLTP - Equivalent AER (km) - Extra High: 85

WLTP - Equivalent AER (km) - City: 100

WLTP - Equivalent AER (km) - Comb: 96

WLTP - Equivalent AER (km) - Comb - TEL: 96

WLTP - Equivalent AER (km) - Comb - TEH: 93

WLTP - EC AC Weighted (kWh/100km) - Comb: 21.4

WLTP - EC AC Weighted (kWh/100km) - Comb - TEL: 21.4

WLTP - EC AC Weighted (kWh/100km) - Comb - TEH: 22.1

WLTP - EC AC Ch Dep (kWh/100km) - Comb: 23

WLTP - AER (miles) - City: 61.5

WLTP - AER (miles) - Comb: 57.8

WLTP - EC (miles/kWh) - City: 3

WLTP - EC (miles/kWh) - Comb: 2.9

WLTP - EC (miles/kWh) - Extra High: 2.5

WLTP - EC (miles/kWh) - High: 3.1

WLTP - EC (miles/kWh) - Low: 2.8

WLTP - EC (miles/kWh) - Medium: 3.1

WLTP - EC AC Ch Dep (miles/kWh) - Comb: 2.7

WLTP - EC AC Weighted (miles/kWh) - Comb: 2.9

WLTP - EC AC Weighted (miles/kWh) - Comb - TEH: 2.8

WLTP - EC AC Weighted (miles/kWh) - Comb - TEL: 2.9

WLTP - Equivalent AER (miles) - City: 62.1

WLTP - Equivalent AER (miles) - Comb: 59.7

WLTP - Equivalent AER (miles) - Comb - TEH: 57.8

WLTP - Equivalent AER (miles) - Comb - TEL: 59.7

WLTP - Equivalent AER (miles) - Extra High: 52.8

WLTP - Equivalent AER (miles) - High: 64

WLTP - Equivalent AER (miles) - Low: 57.8

WLTP - Equivalent AER (miles) - Medium: 65.2

Battery Capacity % guaranteed under warranty: 70

Charging Port Location: Right Side Rear

Usable Battery Capacity: 19.5

Maximum Charging Rate - kW: 11

Test Cycles

Emissions Test Cycle: WLTP

RDE Certification Level: RDE 2

Emissions - PHEV

WLTP - CO2 Ch Sus (g/km) - Low: 234

WLTP - CO2 Ch Sus (g/km) - Medium: 157

WLTP - CO2 Ch Sus (g/km) - High: 144

WLTP - CO2 Ch Sus (g/km) - Extra High: 164

WLTP - CO2 Ch Sus (g/km) - Comb: 166

WLTP - CO2 Charge Depleting (g/km) - Comb: 8

WLTP - CO2 Weighted (g/km) - Comb: 20

WLTP - CO2 Weighted (g/km) - Comb - TEL: 20

WLTP - CO2 Weighted (g/km) - Comb - TEH: 22

Fuel Consumption - PHEV

WLTP - FC Ch Sus (mpg) - Low: 27.2

WLTP - FC Ch Sus (mpg) - Medium: 40.9

WLTP - FC Ch Sus (mpg) - High: 44.8

WLTP - FC Ch Sus (mpg) - Extra High: 38.7

WLTP - FC Ch Sus (mpg) - Comb: 38.7

WLTP - FC Ch Sus (l/100km) - Low: 10.4

WLTP - FC Ch Sus (l/100km) - Medium: 6.9

WLTP - FC Ch Sus (l/100km) - High: 6.3

WLTP - FC Ch Sus (l/100km) - Extra High: 7.3

WLTP - FC Ch Sus (l/100km) - Comb: 7.3

WLTP - FC Ch Dep (l/100km) - Comb: 0.1

WLTP - FC Weighted (l/100km) - Comb: 0.9

WLTP - FC Weighted (l/100km) - Comb - TEL: 0.9

WLTP - FC Weighted (l/100km) - Comb - TEH: 1

WLTP - FC Ch Dep (mpg) - Comb: 2824.8

WLTP - FC Weighted (mpg) - Comb: 313.9

WLTP - FC Weighted (mpg) - Comb - TEL: 313.9

WLTP - FC Weighted (mpg) - Comb - TEH: 282.5
